| POWDER COMPACTING PRESS MAIN BODY SPECIFICATION |
| MODEL |
PT-20(KM-20) |
| MAX PRESSING CAPACITY(ton) |
20 |
| EJECTION CAPACITY(ton) |
10 |
| DIE FLOAT STOP CAPACITY(ton) |
10 |
| TOP PUNCH STROKE (mm) |
130 |
| TOP PUNCH ADJUSTMENT (mm) |
MANUAL 60 |
| MAX DEPTH OF FILLING (mm) |
100 |
| MAX EJECTION STROKE (mm) |
70 |
| OVER FILL (mm) |
5 |
| SPEED DEVICE |
INVERTER |
| STROKE PER MINUTE (spm) |
10-40 |
| STROKE SPEED ADJUSTMENT |
REVOLVER OR AUTO |
| CLUTCH & BREAK |
AIR PRESSURE TYPE |
| TOP PUNCH HOLD DOWN |
EQUIPED |
| DIE FLOATER ADJUSTMENT (mm) |
MANUL ±5 |
| LUBRICATION |
AUTO |
| FEEDER DEVICE |
CAM VIBRATION |
| STROKE OF FEEDER (mm) |
140 |
| POWDER TANK CAPACITY (L) |
13 |
| MAX DIAMETER OF PRODUCT |
70ψ |
| POWDER CHECK SENSOR |
EQUIPED |
| LAST PRESSING STROKE( mm) |
0~8 |
| DIE FLOAT CONTROL DEVICE |
SCREW |
| PRESS INDICATOR |
HIGHER HIGH & LOW LIMIT |
| ANGLE CONTROLLER |
ELECTRON 23POINT |
| ACCUMULATIVE COUNTER |
EQUIPED 7 NUMBERS |
| PRODUCTION COUNTER |
EQUIPED 7 NUMBERS |
| AIR CONSUMPTION |
50 L / MIN (20SPM) |
| POWER SOURCE VOLTAGE |
3∮ 220V 380V 440V 50Hz 60Hz AS SIGH |
| OPERATE VOLTAGE |
110V 60Hz DC24V |
| OPERATION |
INCHINE CONTINIOUS SAFETY ONE CYCLE REV |
| MAIN MOTOR (kw) |
5.5 |
| WEIGHT OF PRESS |
2 TON |
| DIMENSION OF MACHINE H×D×W (mm) |
H2950×W1450×D1000 |
| DIE SET SPECIFICATION |
| TOP PUNCH STOP CAPACITY(ton) |
20 |
| UPPER 2ND PUNCH STOP CAPACITY(ton) |
7.5 |
| DIE FLOAT STOP CAPACITY ( ton) |
10 |
| LOWER 1ST PUNCH STOP CAPACITY(ton) |
20 (FIXED) |
| LOWER 2ND PUNCH STOP CAPACITY(ton) |
15 (MOVABLE) |
| LOWER 3RD PUNCH STOP CAPACITY(ton) |
15 (FIXED) |
| CORE STOP CAPACITY(ton) |
－ |
| UPPER 1ST PUNCH ADJUSTMENT STROKE(mm) |
12 |
| UPPER 2ND PUNCH ADJUSTMENT STROKE (mm) |
20 |
| LOWER 1ST PUNCH FILLING ADJUSTMENT(mm) |
FIXED |
| LOWER 2ND PUNCH FILLING ADJUSTMENT(mm) |
70 EQUIPED |
| CORE EJECTION ADJUSTMENT(mm) |
－ |
| UPPER 2ND PUNCH GAP ADJUSTMENT(mm) |
2 |
| LOWER 1ST GAP ADJUSTMENT(mm) |
FIXED |
| LOWER 2ND PUNCH GAP ADJUSTMENT(mm) |
30 |
| LOWER 1ST PUNCH ADJUSTMENT(mm) |
±5 |
| LOWER 2ND PUNCH ADJUSTMENT(mm) |
±5 INDIVIDUAL |
| FLOATING CORE(mm) |
EQUIPED |
| CORE ROD (mm) |
EQUIPED |
| WEIGHT OF DIE SET (kg) |
200 |
