The Feature of Model- PB |
|
| |
1. The top punch movement drives by curved wheel 、 extend filling time、smooth pressing curve.
When pressing, it's continuing press and curved press between 10° ∼ 15°, and have a better stroke
effect. The stroke per minute is fast、high-steady、used for some big compress materials such as
oxidative iron and ceramics materials, etc.
2. This equipment adopts machine design, non-grease, it doesn't fix the stroke per minute when the
temperature changes.
3. This equipment adopts dry pressing indicator.
4. The center of machine's construction is below, it can be steady when it works.
5. It's easy to learn and operate for adopting fixed ejection position.
6. Forced lubrication automatically by motor pump, it's higher safety and lower rate of the breakdown.
7. Each adjustment construction equips the counter. Ex: top punch adjustment、filling adjustment、
ejection adjustment、last press adjustment.
8. The lower level of the machines equips the press stop, it can accomplish the stroke of the die float
and core. |
|
| |
|
|
| |
◎
The Feature of Model- PT |
|
| |
1. The equipment is machine powder compaction press.
2. Die set's model has fixed ejection position.
3. The top punch adopts curved driving and pressing.
4. The press's power point is in machine's center, the construction is simple, the frictional force power
is low, the breakdown's rate is less and the maintenance is easy.
5. Forced lubrication automatically by motor pump, or used grease No. 0.
6. Each adjustment construction equips the counter, including: top punch adjustment
、 filling adjustment 、 ejection adjustment 、 last press adjustment.
7. The lower level of the machines equips the press stop, it can accomplish the stroke of the die float
and core.
8. The powder tank has serve equipment. (You can select it or not.)
9. There are 3 axis (the top punch 、 filling ejection) have easy CNC equipment. (You can select it
or not.)
10. The die-set changes rapidly. (You can select it or not.) |
|
| |
|
|
| |
◎
The Features of Die Set |
|
| |
1. The movement of the upper 1st punch and the upper 2nd punch can adjust finely.
2. The upper 2nd punch gap can adjust ±1.5mm finely.
3. The ejection axis of the lower 1st punch and the lower 2nd punch has adjustment ability.
(The adjustment is around 1/2 of the filling stroke.)
4. The ejection axis of the lower 1st punch and the lower 2nd punch can be continuous movement
ability. (The machine must be over 80 ton can have this ability.)
5. The standard die set model, including:
A: the upper 1 and the lower 1.
B: the upper 1 and the lower 2.
C: the upper 2 and the lower 3. |
|
| |
|
|
|
 |
